BS2A-ODPB

BioStation 2a Fingerprint + Dual RFID

BS2A-ODPB, SUPREMA, Biometric readers, Access Control, Biometric identification : Fingerprint, Wiegand interface : 1x In or Out, Power supply : 12VDC, 24VDC, POE, BioStar software compatibility : From BioStar 2.x, Max users [1:1] : 500000, IP Ethernet : RJ45 - Min. Cat 5 - 10/100 Base T, Warranty : 2 Years, BS2A-ODPB, SUPREMA, Biometric readers, Access Control, Biometric identification : Fingerprint, Wiegand interface : 1x In or Out, Power supply : 12VDC, 24VDC, POE, BioStar software compatibility : From BioStar 2.x, Max users [1:1] : 500000, IP Ethernet : RJ45 - Min. Cat 5 - 10/100 Base T, Warranty : 2 Years, BS2A-ODPB, SUPREMA, Biometric readers, Access Control, Biometric identification : Fingerprint, Wiegand interface : 1x In or Out, Power supply : 12VDC, 24VDC, POE, BioStar software compatibility : From BioStar 2.x, Max users [1:1] : 500000, IP Ethernet : RJ45 - Min. Cat 5 - 10/100 Base T, Warranty : 2 Years,

  • Biometric identification : Fingerprint
  • Wiegand interface : 1x In or Out
  • Power supply : 12VDC, 24VDC, POE
  • BioStar software compatibility : From BioStar 2.x
  • Max users [1:1] : 500000
  • IP Ethernet : RJ45 - Min. Cat 5 - 10/100 Base T
  • Warranty : 2 Years

Features

BS2A-ODPB

External Interface

Serial interface RS485
USB Interface 1 x USB Rear Pannel
Wiegand interface 1x In or Out

Environmental

Working Temperature (°C) From -20 to 60
Weight 0.571
Weather Proof IP Rating 65
Tamper Back contact
Dimensions (H x W x D) [mm] 144 x 142 x 45

Specifications

Power supply 12VDC, 24VDC, POE
Current max [mA] 800
LED display none
Touchscreen No
LCD display 2.8" Color
Sound 16 Bit Hi-Fi
QR-Code reader No
Warranty 2 Years
Intercom function No
RFID technology versions EM 125KHz, FeliCa 13.56 MHz, HID 125 KHz, MIFARE Classic, MIFARE Desfire (CSN), MIFARE Desfire EV1, MIFARE Desfire EV2, MIFARE Desfire EV3, MIFARE Plus
RFID technologies BLE, EM, FeliCa, Mifare, NFC
RFID encryption Programmable

Programmable Wired Outputs

Relay outputs 1

Network

IP Ethernet RJ45 - Min. Cat 5 - 10/100 Base T

Programmable Wired Inputs

Number of wired inputs 3

System

Memory RAM 2GB
Memory Flash 16GB
CPU 1.5GHz Quad Core

Biometrics

Biometric identification Fingerprint

Capacity

Max users [1:1] 500000
Max users [1:N] 100000
Max. templates (1:1) 500000
Max. templates (1:N) 100000
Max. text log events 5000000

Features

BioStar compatibility From BioStar 2.x

Wifi

WiFi none
