DJI Matrice 4 Thermal
Matrice 4 Thermal
- Usage : Precise aerial inspection from long distances, Safety, Security and Inspection, Thermal and RGB imaging
- Max flight time (minutes) : 49
- Maximum distance : 25 Km.
- Drone Type : Quadcopter
- Warranty : 2 Years
- Manufacturer ref. : 190021119321
- Features
-
DJI Matrice 4 Thermal
- Basic informations
- Specifications
- Camera
- Drone
- Payload
- Thermal camera
- Laser module
- Remote controller
- Transmission
- Features
- Environmental
- Regulations
Basic Informations
EAN Code 6941565994226 Manufacturer ref. 190021119321 Specifications
Warranty 2 Years Camera
Video Frame Rate 1920x1080@30fps, 3840x2160@30fps Video Bitrate 4K: 85 Mbps FHD: 30 Mbps Video Compression H.264, H.265 Sensor 1/1.5-inch CMOS (7x telephoto), CMOS 1/1,3 pouce, pixels effectifs : 48 Mpx Lens 24 mm (wide-angle), 70 mm (medium telephoto), 168 mm (7x telephoto) ISO from 100 to 25600 (picture) Image format JPEG Video format MP4 Image max. resolution Wide: 8064 × 6048 Medium Telephoto: 8064 × 6048 Telephoto: 8192 × 6144 Exposure modes Auto, Manual Operation modes Capture / Record / Playback Still photography modes Panorama (Sphère), Single shot / Interval (2/3/5/7/10/15/20/30/60) Digital Zoom 16x (112x hybrid zoom) Drone
Max. ascent speed (km/h) 36 Max. descent speed (km/h) 29 Usage Precise aerial inspection from long distances, Safety, Security and Inspection, Thermal and RGB imaging Drone Type Quadcopter Dimensions unfolded (mm) 307.0×387.5×149.5 mm (L×W×H) Dimensions folded (mm) 260.6×113.7×138.4 mm (L×W×H) Batteries number 1 Battery capacity / Battery weight 6741 mAh / 401 g Navigation BeiDou, GPS (L1/L2), Galileo (E1/E2), Glonass (L1/L2) Redundancy & Sensors Dual GNSS, Dual IMU Flight control Custom built-in Remote controller RC PLUS 2 Remote video output ports HDMI, USB Operating frequency 2.4 GHz (CE <20 dBm), 5.7-5.8 GHz (CE <14 dBm) Maximum distance 25 Km. Obstacle avoidance Bottom: 0.3 to 18m / 130° (front and back), 160° (left and right), Front : 0,5 to 200m / H : 90° V : 103, Height: 0.2 to 10m / 100° (front and back), 90° (left and right), Lateral : 0,5 to 25m / H : 90° V : 85 Apps DJI Pilot 2 (Android & iOS) Max. altitude sea level (m) 6000 Max flight time (minutes) 49 Max. speed (km/h) 76 Max. take-off weight (kg) 1.43 Weight incl. batteries and propellers (kg) 1.229 Payload
Camera stabilisation 3-axis (pitch, roll, yaw) Angular vibration range in ° 0.007 Controllable range Tilt: -90 to 35°; pano: -5° to 5 Mechanical range Tilt: +45º to -135º / Pan: ±100º Thermal Camera
Thermal resolution 1280 x 1024 Other features - Color mode: D-CineLike
- D-HDR – 13 RAW pictures
Sensor uncooled vanadium oxide (VOx) Focal DFOV: 45°±0.3° equivalent focal length: 53 mm Aperture: f/1.0 Focus: 5 m to ∞ Digital Zoom 28x Pixel Pitch 12 μm Spectral Band 8-14 μm Photo format JPEG, R-JPEG Video format MP4 Metering method Area mesurement, Isotherms, Spot Meter, Temperature Alert Sensitivity NETD ≤50 mK @ f/1.0 Temperature alert Yes Laser Module
Wave length 1800 m Measuring accuracy 1-3 m: System Error <0.3 m, Random Error <0.1 meters @1σ Other Distances: ±(0.2+0.0015D) (D represents the measurement distance in meters) Remote Controller
Screen 7.02 inch LCD touchscreen, with a resolution of 1920×1200 pixels, and high brightness of 1200 cd/m2 Internal Battery Type: Li-ion (6500 mAh @ 7.2 V) Charge Type: Supports battery station or USB-C charger maximum rated power 65W (max voltage of 20V) Charge Time: 2 hours Chemical System: LiNiCoAIO2 Operating time Internal Battery: Approx. 3 hours 18 minInternal Battery + External Battery: Approx. 6 hours Model RC PLUS 2 Operating Temperature -20° to 50° C (-4° to 122° F) Transmission
Video transmission OcuSync 4 Enterprise Features
Product description The DJI Matrice 4T redefines professional drone standards with its advanced multi-sensor capabilities and artificial intelligence (AI) integration.This drone is perfectly suited to the public safety, technical inspection and environmental management sectors.Equipped with a hybrid zoom of up to 112x, an Ultra High Resolution thermal camera and a precise laser rangefinder, it enables detailed surveys even in difficult conditions. Its 12 km range (CE standard) and 49-minute autonomy guarantee peace of mind for extended missions. Designed for complex environments, it excels in areas with weak GNSS signals or low light levels, thanks to its visual positioning capabilities and high-performance sensors.The Matrice 4T is also distinguished by its new RC Plus 2 radio control system, equipped with an ultra-bright 1400 nits display, for optimum control in all circumstances. Synchronized with the FlightHub 2 platform, it offers advanced mission management functions and integration into modern workflows.With its rugged design and modular accessories, the DJI Matrice 4T is the must-have tool for demanding professionals!Contents of the package - Drone DJI Mavic 4T
- Cradle protection
- Radio control DJI RC PLUS 2
- Smart battery x1
- Charger
- 64 GB microSD card x1
- Low-Noise propellers x3
- USB to USB-C cable x1
- USB-C to USB-C cable
- Case
- DJI CARE BASIC
Environmental
Working Temperature (°C) From -10 to 40 Weather Proof IP Rating None Regulations
Drone category (EU) Open Drone class (EU) C2 - Download
-
