DS-KD9403-E6(O-STD)
Face recognition terminal 8"
- POE Interface : None
- Network Interface : 2x RJ-45 10/100/1000 Mbps Ethernet
- Supervision software compatibility : HikCentral, HIK-Connect, HIK-Partner PRO, iVMS-4200
- Biometric identification : Face recognition
- LCD display : 8'' 1280x800 Multi-Touch
- Manufacturer ref. : 305302789
- Features
-
DS-KD9403-E6(O-STD)
- Lighting
- Specifications
- Intercom
- Built in functions
- Basic informations
- External interface
- poe
- Camera
- Environmental
- Video Audio input
- Certifications
- Wifi
- Biometrics
- Audio Video output
- Network
- Specific Intercom function
- Specific function Access control
Lighting
Infrared LEDs Yes White LEDs No Specifications
Touchscreen Yes Intercom function Yes Image memory Yes SD slot Yes Voice messages Yes Call forwarding to phone Yes Power supply 12VDC Keypad Yes Card technology Mifare Desfire 13.56MHz Warranty 3 Years Power consumption (W) 18 LCD display 8'' 1280x800 Multi-Touch Language English, French, German, Italian, Multilingual, Multilingual, including french Supervision software compatibility HIK-Connect, HIK-Partner PRO, HikCentral, iVMS-4200 Strike power supply No Customisation of the interface Customize function keys, Photo customization, Video customisation iOS & Android Apps compatibility Yes Intercom
SIP & VoIP Services Yes Audio CODEC G711 u/a Built In Functions
OnVif No WDR Wide Dynamic Range D-WDR Digital WDR Analyzes Facial recognition, QR Code, Simple mouvement Basic Informations
EAN Code 6931847130558 Manufacturer ref. 305302789 External Interface
Network Interface 2x RJ-45 10/100/1000 Mbps Ethernet Serial interface RS485 USB Interface 1x USB (HIK debog), 1x USB (HIK module) Wiegand interface 1x In or Out, 26 bits, 34 bits Alarm Input 4 Alarm output 2 Bluetooth No Number of inputs 1 door control button (+1 with K2M), 1 output button (+1 with K2M) Number of relay outputs 1 strike (+1 with K2M) Number of master screens configurable in master doorphone 500 Number of slave gatekeepers configurable in the master gatekeeper 16 Number of slave screens configurable in master screen 5 Number of DoorPhone configurable in the master screen 32 Number of cameras configurable as direct link in master screen 16 Number of alarms and calls manageable (KM9503) 10000 Number of doorphone/cameras manageable (KM9503) 128 Poe
POE Interface None Camera
Video Frame Rate 1920x1080@25fps Video Resolution 1080p Video Compression H.264 Angle of View max. : Horizontal (°) 88 Image Sensor 2MP CMOS IMAGE SENSOR Environmental
Mounting Flush, Surface Colour Silver Tamper Back contact Working Temperature (°C) From -30 to 60 Working Humidity [%] From 10 to 90 Weather Proof IP Rating 65 Material Aluminium & acrylic IK Shock Rating None Dimensions (H x W x D) [mm] 145 x 244 x 26 Video Audio Input
Audio in Integrated microphone Certifications
Standards For the hearing and visually impaired - SIA 500 Wifi
WiFi No Biometrics
Recognition speed 0.2 Biometric identification Face recognition Fingerprint sensor type Capacitive Audio Video Output
Audio Output HD speaker integrated Network
Web Browser Access Yes Mobile network No Network Protocols RTSP, TCP/IP Specific Intercom Function
Physical call button No Communication on HIK-Connect With screen SIP management Relay 1 via SIP 1#, Relay 2 via SIP 2#, SIP call, SIP video Configurable call list Yes Configurable call calendar Call barring only Device Management Ready On Board Yes Configurable call diversion No Call group No Slave doorphone management (SubDoorCapacity) 16 Volume control Alert, Loudspeaker, Microphone, Ring Voice Prompt Deactivatable No Specific Function Access Control
Controller No SecureDoor module K2M060, K2M061 Remote card reader Yes via RS485 Elevator module K2M0016A External module Digicode, Fingerprint Configurable access schedule No Multiple simultaneous authentication Yes Differential door relay Yes Individual time management Yes Number of users (minimum) 20000 - Download
-
