DS-TPM400-P(3T)
Guidance Terminal 32 Ch.
- Total video channels : 32
- DeepinMind (AI) canals : 32
- DeepinLearning (AI) Analyse : Vehicle recognition
- Optional discs : 8x SATA
- RAID Type : No
- Series : Parking Management
- Warranty : 3 Years
- Manufacturer ref. : 305901095
- Features
-
DS-TPM400-P(3T)
- Video Audio input
- Network
- Decoding
- Audio Video output
- Hard disk
- RAID
- External interface
- Specifications
- Environmental
- poe
- Built in functions
- Certifications
- Camera
- Deep Learning
- Basic informations
- Others
Video Audio Input
Number of IP channels 32 Two Way Audio Input 1-ch, RCA ( 2.0Vp-p , 1kohm ) IP Video Input Maximum Resolution 3 MP Video Input Technology IP Total video channels 32 Network
Incoming Bandwidth 320 Outgoing Bandwidth 250 Remote connection 128 Web Browser Access Internet Explorer Total LAN ports 12 Number of PoE ports 8 Number of SFP ports 1 Decoding
Recording resolution (encoding) 1.3MP, 1080p, 3MP Decoding capability 16-CH 960x576p Audio Video Output
HDMI Output 1 VGA Output 0 Audio Output 1-ch, RCA (2.0Vp-p , 1Kohm ) Monitor resolution 1080p LCD monitor No Video Output for 4K 1x HDMI 1.4b Hard Disk
Optional discs 8x SATA eSATA 1 HD Capacity None redundant recording No RAID
RAID Type No Number of Raid Arrays 0 External Interface
Network Interface 4x RJ-45 10/100/1000 Mbps Ethernet Optical Interface 1 x 1Gbps Serial interface RS232, RS485 USB Interface 1 x USB 2.0 Type-A / 1 x USB 3.1 Type-C Alarm Input 3 Alarm output 3 Specifications
Power consumption (W) 500 Power supply 230VAC Signal System HDMI, IP Warranty 3 Years Environmental
Working Temperature (°C) From -10 to 50 Working Humidity [%] From 10 to 90 Weight 10 Chassis Tower Redundant Power Supply No 19" Rack mounting No Dimensions (H x W x D) [mm] 540 x 410 x 130 Poe
POE Interface 8 x POE 100Mbps POE Interface Standard 24VDC POE HIKVISION Built In Functions
Analyzes depending on the Hikvision camera E-Mail Events, system error Certifications
Video resolution Full HD Camera
Video Compression H.264, H.264+, H.265, H.265+, MPEG4 Deep Learning
DeepinLearning (AI) Analyse Vehicle recognition Comparative research None Face picture libraries None Face capture channels None humans / vehicles capture channels None Basic Informations
Manufacturer ref. 305901095 Others
DeepinMind (AI) canals 32 - Download
-
